Fluidized Bed Dryer (FBD)
A fluidized bed dryer (FBD) is well known and widely used for granulation process to attain desired moisture levels in the granules or powders required for the perfect compression of tablet formulations in pharmaceutical industry. Moisture content is removed by introducing heated and purified dry air through fluidized bed under negative pressure.
Technical Specifications
- Heating Options
- Steam and electric heating
- MOC
- SS304, SS316
Key Features & Capabilities
- Pharmaceutical granulation specialist
- Steam and electric heating options
- In-built CIP system
- 225 to 1,700 Litre SS container range
Standard Models & Dimensional Specifications
Engineering data sheet and capacity matrix for Fluidized Bed Dryer (FBD)
| Model No. | Capacity (L) | A.H.U. (CFM) | Dimensions (mm) | Steam (Kg/hr) | Power (HP) |
|---|---|---|---|---|---|
| FBD-060 | 225 | 4000 | 2800×1100×1500 | 50 | 10 |
| FBD-120 | 425 | 6000 | 3000×1800×2000 | 100 | 15 |
| FBD-200 | 715 | 9000 | 3200×2000×2200 | 130 | 25 |
| FBD-250 | 750 | 9000 | 3200×2100×2200 | 130 | 25 |
| FBD-300 | 900 | 9000 | 3200×2100×2200 | 130 | 30 |
| FBD-500 | 1700 | 16000 | 4000×2700×2500 | 150 | 30 |
Custom capacities, materials of construction (SS316L, Hastelloy, Titanium), and automated CIP/PLC controls available upon request.
